Ecological scientists have collected abundant data: climate change, underground water movement, air condition, etc. With machine learning, we can learn knowledge from those data, which will help solve environmental problems.
Most of the time, machine learning means complex mathematics concepts and many lines of code, which creeps many people out. But with Azure Machine Learning, your task will go easier.
We thus bring to you, a comparison on the development procedure of a Convolutional Neural Network (CNN) - a Deep Learning Model (subset of Machine Learning) using two different sets of methodologies:
Traditional Methodology - Importing Python libraries, Dataset collection-preprocessing, breaking our heads over it, etc.
Azure ML Methodology - Easy tasks, Easier tasks, Way more Easier tasks, etc.
Traditional Methodology 🧠
Below is a step-by-step approach on how we developed a CNN Model, which performs the task of Object Recognition, Classification and Detection.
We have used the cifar10 Dataset to Train the Model, which provides it with the capability to recognize and classify 10 Different Classes of objects.
This is the link to the GitHub Repository containing all the required code for building the Model.
Step 1
Import the required libraries.
import numpy as np
from keras.models import Sequential
from keras.layers import Dense, Dropout, Flatten, BatchNormalization, Activation
from keras.layers.convolutional import Conv2D, MaxPooling2D
from keras.constraints import maxnorm
from keras.utils import np_utils
from keras.datasets import cifar10
import PIL.Image as Image
from cv2 import *
The most Important and Noteworthy libraries are - Keras, cv2 and NumPy.
Step 2
Prepare, Pre-process and Filter the Dataset. As the Dataset chosen here is relatively small compared to worldly data, this might not seem to be too much of a tedious task.
# Set random seed for purposes of reproducibility
seed = 21
# Loading in the data
(X_train, y_train), (X_test, y_test) = cifar10.load_data()
# normalize the inputs from 0-255 to between 0 and 1 by dividing by 255
X_train = X_train.astype('float32')
X_test = X_test.astype('float32')
X_train = X_train / 255.0
X_test = X_test / 255.0
# one hot encode outputs
y_train = np_utils.to_categorical(y_train)
y_test = np_utils.to_categorical(y_test)
class_num = y_test.shape[1]
Step 3
Decide the Dimension of the Model (Conv2D - a 2D Model) and create various layers of the Model, namely Input, Hidden and Output layers.
The Input Size of each layer is dependent on the size of the previous as well as input layers. The Activation Function must be selected according to the operation performed by the Model. Make sure to include a Dropout Rate at each layer to avoid Overfitting ( A Model which predicts 'too closely or exactly' to a particular set of data is said to be an Overfitted Model )
model = Sequential()
model.add(Conv2D(32, (3, 3), input_shape=X_train.shape[1:], padding='same'))
model.add(Activation('relu'))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Conv2D(64, (3, 3), padding='same'))
model.add(Activation('relu'))
model.add(MaxPooling2D(pool_size=(2, 2)))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Conv2D(64, (3, 3), padding='same'))
model.add(Activation('relu'))
model.add(MaxPooling2D(pool_size=(2, 2)))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Conv2D(128, (3, 3), padding='same'))
model.add(Activation('relu'))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Conv2D(256, (3, 3), padding='same'))
model.add(Activation('relu'))
model.add(MaxPooling2D(pool_size=(2, 2)))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Flatten())
model.add(Dropout(0.2))
model.add(Dense(256, kernel_constraint=maxnorm(3)))
model.add(Activation('relu'))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Dense(128, kernel_constraint=maxnorm(3)))
model.add(Activation('relu'))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Dense(64, kernel_constraint=maxnorm(3)))
model.add(Activation('relu'))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Dense(64, kernel_constraint=maxnorm(3)))
model.add(Activation('relu'))
model.add(Dropout(0.2))
model.add(BatchNormalization())
model.add(Dense(class_num))
model.add(Activation('softmax'))
Step 4
Declare the number of Epochs you'd like to run on the Model and finally, Compile it !
Don't forget to print out the Accuracy of your model. You'd want it to be as accurate as possible.
Finally, Save your Model, for future use and integrations with other projects/applications you might build !
epochs = 25
optimizer = 'adam'
model.compile(loss='categorical_crossentropy', optimizer=optimizer, metrics=['accuracy'])
print(model.summary())
numpy.random.seed(seed)
model.fit(X_train, y_train, validation_data=(X_test, y_test), epochs=epochs, batch_size=64)
# Model evaluation
scores = model.evaluate(X_test, y_test, verbose=0)
print("Accuracy: %.2f%%" % (scores[1] * 100))
model.save('CNN_ImageProcessing.h5')
Phew ! That was so much work ‼
Now, let's look into how you'd perform the same set of tasks (way lesser and easier tasks) using Azure ML 🎉
Easy (Azure ML) Methodology 🥂
Below is a step-by-step approach to one of the most Difficult ways of using the user-friendly Azure ML Service - via the Command Line Interface (CLI) , and we are confident, you will still find this easier than the previous procedure.
That's a bold statement to make ain't it ?
Step 1
Install the Azure ML Extensions for the Azure CLI by running the following command:
$ az extension add -n azure-cli-ml
You now have access to the Azure ML Command Line Tools via the CLI.
Step 2
Create a new resource group for the Azure ML Workspace, by running the following command.
$ az group create -n ml -l southindia
$ az ml workspace create -w mldws -g ml
Note: Remember to change the region to the Azure Region nearest to you. (Change 'southindia' to your desired region. Lookup this Gist by ausfestivus if you aren't sure about the region closest to you.)
Step 3
Change to the Working Directory in your shell and export an Azure ML Workspace config to the disk.
$ az ml folder attach -w mlws -g ml -e mls
Finally, install the python extension to interact with Azure ML from within python by running the following command:
python3 -m pip install azure-cli azureml-sdk
Now, simply navigate to the Machine Learning workspace on the Azure Portal and open the Azure Machine Learning interface to use the Notebook Viewer provided.
To run your code on this Environment, click on Compute -> Create Compute Instance. When completed, an option to start a Jupyter Notebook pops up automatically.
Step 4
Surprise !! 🌟 All the handwork's done above. All you need to do now is:
- Create a Machine Learning instance.
- Choose from Trained Datasets, Automated ML, Designer Drag and Drop Model Deployment Interface and loads more. (More about these on upcoming blogs !)
- Relax ‼️
If we're doing the right math, not only is it way easier to create a Model using Azure ML, but the lines of code reduce drastically too !
We'd like to call an end to this exercise of comparison and we think, Azure ML is MILES AHEAD of the traditional method of ML Model Development. 🎉
